New cathode material could triple Li-ion battery storage

US researchers have developed a new cathode material from iron fluoride that surpasses the capacity limits of traditional lithium-ion batteries, potentially tripling the energy density of lithium-ion battery electrodes. The results of their work have been published in the journal Nature Communications.

As the demand for smartphones, electric vehicles and renewable energy continues to rise, scientists are searching for ways to improve lithium-ion batteries — the most common type of battery found in home electronics and a promising solution for grid-scale energy storage. Now, a collaboration led by scientists at the University of Maryland (UMD), the US Department of Energy’s (DOE) Brookhaven National Laboratory and the US Army Research Lab has made significant progress towards that goal.

“Lithium-ion batteries consist of an anode and a cathode,” said Xiulin Fan, a scientist at UMD and one of the lead authors of the paper. “Compared to the large capacity of the commercial graphite anodes used in lithium-ion batteries, the capacity of the cathodes is far more limited. Cathode materials are always the bottleneck for further improving the energy density of lithium-ion batteries.”

Scientists at UMD synthesised a new cathode material, a modified and engineered form of iron trifluoride (FeF₃), which is composed of cost-effective and environmentally benign elements — iron and fluorine. Researchers have been interested in using chemical compounds like FeF₃ in lithium-ion batteries because they offer inherently higher capacities than traditional cathode materials.

“The materials normally used in lithium-ion batteries are based on intercalation chemistry,” said Enyuan Hu, a chemist at Brookhaven and one of the lead authors of the paper. “This type of chemical reaction is very efficient; however, it only transfers a single electron, so the cathode capacity is limited. Some compounds like FeF₃ are capable of transferring multiple electrons through a more complex reaction mechanism, called a conversion reaction.”

Despite FeF₃’s potential to increase cathode capacity, the compound has not historically worked well in lithium-ion batteries due to three complications with its conversion reaction: poor energy efficiency (hysteresis), a slow reaction rate and side reactions that can cause poor cycling life. To overcome these challenges, the scientists added cobalt and oxygen atoms to FeF₃ nanorods through a process called chemical substitution. This allowed the scientists to manipulate the reaction pathway and make it more ‘reversible’.

“When lithium ions are inserted into FeF₃, the material is converted to iron and lithium fluoride,” said Sooyeon Hwang, a co-author of the paper and a scientist at Brookhaven’s Center for Functional Nanomaterials (CFN). “However, the reaction is not fully reversible. After substituting with cobalt and oxygen, the main framework of the cathode material is better maintained and the reaction becomes more reversible.”

Substituting the cathode material with oxygen and cobalt prevents lithium from breaking chemical bonds and preserves the material’s structure.

To investigate the reaction pathway, the scientists conducted multiple experiments at CFN and the National Synchrotron Light Source II (NSLS-II) — two DOE Office of Science User Facilities at Brookhaven.

First at CFN, the researchers used a powerful beam of electrons to look at the FeF₃ nanorods at a resolution of 0.1 nm — a technique called transmission electron microscopy (TEM). The TEM experiment enabled the researchers to determine the exact size of the nanoparticles in the cathode structure and analyse how the structure changed between different phases of the charge-discharge process. They saw a faster reaction speed for the substituted nanorods.

“TEM is a powerful tool for characterising materials at very small length scales, and it is also able to investigate the reaction process in real time,” said Dong Su, a scientist at CFN and a co-corresponding author of the study. “However, we can only see a very limited area of the sample using TEM. We needed to rely on the synchrotron techniques at NSLS-II to understand how the whole battery functions.”

At NSLS-II’s X-ray Powder Diffraction (XPD) beamline, scientists directed ultrabright X-rays through the cathode material. By analysing how the light scattered, the scientists could ‘see’ additional information about the material’s structure.

“At XPD, we conducted pair distribution function (PDF) measurements, which are capable of detecting local iron orderings over a large volume,” said Jianming Bai, a co-author of the paper and a scientist at NSLS-II. “The PDF analysis on the discharged cathodes clearly revealed that the chemical substitution promotes electrochemical reversibility.”

“We also performed advanced computational approaches based on density functional theory to decipher the reaction mechanism at an atomic scale,” said Xiao Ji, a scientist at UMD and co-author of the paper. “This approach revealed that chemical substitution shifted the reaction to a highly reversible state by reducing the particle size of iron and stabilising the rocksalt phase.”

Scientists at UMD say this research strategy could be applied to other high energy conversion materials, and future studies may use the approach to improve other battery systems.
