'Invisible glass' has almost no surface reflections

Most of today’s electronics devices are equipped with glass or plastic covers for protection against dust, moisture and other environmental contaminants. But as useful as these displays are, they are also responsible for a major nuisance for the modern-day screen addict: glare.

Now, scientists at the Center for Functional Nanomaterials (CFN) — a US Department of Energy facility at Brookhaven National Laboratory — have demonstrated a method for reducing the surface reflections from glass surfaces to nearly zero by etching tiny nanoscale features into them. Their work has been published in the journal Applied Physics Letters.

Whenever light encounters an abrupt change in refractive index (how much a ray of light bends as it crosses from one material to another, such as between air and glass), a portion of the light is reflected. The researchers’ nanoscale features have the effect of making the refractive index change gradually from that of air to that of glass. As a result, reflections are reduced so much that the glass essentially becomes invisible.

To texture the glass surfaces at the nanoscale, the scientists used an approach called self-assembly, which is the ability of certain materials to spontaneously form ordered arrangements on their own. In this case, the self-assembly of a block copolymer material provided a template for etching the glass surface into a ‘forest’ of nanoscale cone-shaped structures with sharp tips — a geometry that almost completely eliminates the surface reflections. Block copolymers are industrial polymers (repeating chains of molecules) that are found in many products, including shoe soles, adhesive tapes and automotive interiors.

The researchers had previously used a similar nanotexturing technique to impart silicon, glass and some plastic materials with water-repellent and self-cleaning properties, and anti-fogging abilities, and also to make silicon solar cells antireflective. The surface nanotextures mimic those found in nature, such as the tiny light-trapping posts that make moth eyes dark to help the insects avoid detection by predators and the waxy cones that keep cicada wings clean.

“This simple technique can be used to nanotexture almost any material with precise control over the size and shape of the nanostructures,” said Atikur Rahman, a former Brookhaven Lab postdoc and co-author on the paper. “The best thing is that you don’t need a separate coating layer to reduce glare, and the nanotextured surfaces outperform any coating material available today.”

“We have eliminated reflections from glass windows not by coating the glass with layers of different materials but by changing the geometry of the surface at the nanoscale,” added co-author Andreas Liapis. “Because our final structure is composed entirely of glass, it is more durable than conventional antireflective coatings.”

Glass surfaces with etched nanotextures reflect so little light that they become essentially invisible. This effect is seen in the above image, which compares the glare from a conventional piece of glass (right) to that from nanotextured glass (left), which shows no glare at all.

To quantify the performance of the nanotextured glass surfaces, the scientists measured the amount of light transmitted through and reflected from the surfaces. In good agreement with their own model simulations, the experimental measurements of surfaces with nanotextures of different heights show that taller cones reflect less light. For example, glass surfaces covered with 300 nm-tall nanotextures reflect less than 0.2% of incoming red-coloured light (633 nm wavelength). Even at the near-infrared wavelength of 2500 nm and viewing angles as high as 70°, the amount of light passing through the nanostructured surfaces remains high — above 95 and 90%, respectively.

In another experiment, they compared the performance of a commercial silicon solar cell without a cover with a conventional glass cover, and with a nanotextured glass cover. The solar cell with the nanotextured glass cover generated the same amount of electric current as the one without a cover. They also exposed their nanotextured glass to short laser pulses to determine the intensity at which the laser light begins to damage the material. Their measurements reveal the glass can withstand three times more optical energy per unit area than commercially available antireflection coatings.

The ultratransparent nanotextured glass was thus found to be antireflective over a broad wavelength range (the entire visible and near-infrared spectrum, or 450–2500 nm) and across a wide range of viewing angles — and it could do a lot more than improve the user experience for consumer electronic displays. It could enhance the energy-conversion efficiency of solar cells by minimising the amount of sunlight lost to refection. It could also be a promising alternative to the damage-prone antireflective coatings conventionally used in lasers that emit powerful pulses of light, such as those applied to the manufacture of medical devices and aerospace components.

“We’re excited about the possibilities,” said CFN Director Charles Black, corresponding author on the paper. “Not only is the performance of these nanostructured materials extremely high, but we’re also implementing ideas from nanoscience in a manner that we believe is conducive to large-scale manufacturing.”
