Using quantum dots for solid-state optical cooling

A team of researchers led by Professor Yasuhiro Yamada from Chiba University have delved into a promising path towards solid-state optical cooling using perovskite quantum dots. Cooling systems are an integral part of many modern technologies, as heat can wear down materials and decrease performance. However, cooling can be an inconvenient and energy-intensive process.

Solid-state optical cooling leverages anti-Stokes (AS) emission; usually, when materials absorb photons from incoming light, their electrons transition into an ‘excited’ state. Under ideal conditions, as electrons return to their original state, part of this excess energy is released as light, while the rest is converted into heat. In materials that undergo AS emission, electrons interact with crystal lattice vibrations called “photons” in such a way that the photons emitted are of higher energy than those in the incident light. If AS emission efficiency is close to 100%, these materials could theoretically cool down, rather than heating up, upon exposure to light.

The researchers delved into this phenomenon in a promising perovskite-based material structure. The researchers sought to shed light on the optical cooling phenomena in a special arrangement of perovskite quantum dots (extremely small CsPbBr3 crystals) embedded within a Cs4PbBr6 host crystal matrix (indicated as CsPbBr3/Cs4PbBr6 crystal).

Yamada said achieving optical cooling in semiconductors can be challenging and true cooling has been elusive. “Quantum dots are promising for their high emission efficiency, they are notoriously unstable, and exposure to air and continued illumination degrade their emission efficiency. Thus, we focused on a stable structure known as ‘dots-in-crystals’, which may overcome these limitations,” Yamada said.

Using semiconducting quantum dots presents an unsolved problem. When light irradiates a semiconductor, it generates excitons — pairs of electrons and positively charged ‘holes’. When excitons recombine, they typically emit light. However, at high exciton densities, a process called Auger recombination becomes more prominent, by which energy is released as heat instead of light. In semiconductor quantum dots, irradiation with high-intensity light often leads to heating instead of cooling because of this process.

Therefore, the researchers used time-resolved spectroscopy to determine the conditions under which Auger recombination occurred more frequently. This showed that heating was unavoidable even at moderate light intensities, implying that experiments under low-intensity light were required to observe true optical cooling. At low intensities, optical cooling becomes less effective; under the best conditions, the researchers’ sample demonstrated a theoretical cooling limit of approximately 10 K from room temperature.

The researchers also aimed to make more reliable temperature measurements than in previously reported efforts. To this end, they developed a method to estimate the temperature of samples with high emission efficiency by analysing the shape of their emission spectrum. True optical cooling was observed in multiple samples and the researchers noted that a transition from cooling to heating occurred as the excitation light intensity was increased.

“Previous reports of optical cooling in semiconductors lacked reliability, primarily due to flaws in temperature estimation. Our study, however, not only established a reliable method, but also defined the potential and limitations of optical cooling through time-resolved spectroscopy, marking a significant achievement in the field,” Yamada said.

The study paves the way for future research focused on reducing Auger recombination to improve the cooling performance of dots-in-crystal arrangements. If optical cooling improves significantly to reach widespread use, it could become the foundation of several energy-saving technologies.

The research findings have been published in the journal Nano Letters.
